FEATURES

Safe And Reliability :Standard dual channel sensor, safe and reliable;Electric emergency power systems provide more security;The protection level of components of the whole machine is above IP65, the protection level is high.

Intelligent And Efficient:Composite action, intelligent and effificient;Electronic differential combined with suspending axle technology for better traffificability;The turntable rotates 360 ° continuously with small tail, which is suitable for narrow space operation;Four wheel strong AC electric drive, climbing capacity up to 45%, strong traffificability;High-power charger, large-capacity power battery, fast charging, ultra-long endurance.

Energy Saving And Comfort:Self -weight decrease through the booms, energy saving and stable;Automatic deceleration at the action limit position, stable action, small shaking;Optimize the electric control algorithm with the load sensitive hydraulic system to achieve accurate power output.

Green And Environmental Protection: Pure electric power, low use and maintenance cost, high return on investment;Green and environmental

protection, no emission, low noise, meet indoor and outdoor working conditions.

SPECIFICATIONS
Dimensions
Max. Work Height 34 m
Max.Platform Height 32m
Max.Operating Range 21.2m →21.8m
Overall Length(Stowed) 11.76 m
Overall Width(Stowed) 2.44 m
Overall Height(Stowed) 2.78 m
Overall Length(Transport) 11.8 m
Overall Width(Transport) 2.27 m
Overall Height(Transport) 2.54 m
Turntable Tailswing(Raised) 1.6 m
Platform Size(L×W×H) 2.4×0.9×1.1 m
Tyres 385/65-24(Solid off-road tyre)
Platform Load(Unrestricted/Restricted) 454kg/300 kg
Gradeability 45 %
Max.Working Slope X-5°/Y-5°
Turret Rotation 360°(Continuous)
Drive Steering Type 4WD×2WS
Battery(Lithium) 83.72V/519Ah→83.2V
Charger 80V/80A
Hydraulic Oil Tank 140 L
