FEATURES

Safe And Reliability :Standard dual channel sensor, safe and reliable;Electric emergency power systems provide more security;The protection level of components of the whole machine is above IP65, the protection level is high.

Intelligent And Efficient:Composite action, intelligent and effificient;Electronic differential combined with suspending axle technology for better traffificability;The turntable rotates 360 ° continuously with small tail, which is suitable for narrow space operation;Four wheel strong AC electric drive, climbing capacity up to 45%, strong traffificability;High-power charger, large-capacity power battery, fast charging, ultra-long endurance.

Energy Saving And Comfort:Self -weight decrease through the booms, energy saving and stable;Automatic deceleration at the action limit position, stable action, small shaking;Optimize the electric control algorithm with the load sensitive hydraulic system to achieve accurate power output.

Green And Environmental Protection: Pure electric power, low use and maintenance cost, high return on investment;Green and environmental

protection, no emission, low noise, meet indoor and outdoor working conditions.

SPECIFICATIONS
Dimensions
Max. Work Height 23.8 m
Max.Platform Height 21.8 m
Max.Operating Range 16.3 m
Overall Length(Stowed) 9.5 m
Overall Width(Stowed) 2.42 m
Overall Height(Stowed) 2.47 m
Overall Length(Transport) 9.5 m
Overall Width(Transport) 2.28 m
Overall Height(Transport) 2.27 m
Turntable Tailswing(Raised) 1.65 m
Platform Size(L×W×H) 2.4×0.9×1.1 m
Tyres 385/65-24(Solid off-road tyre)
Platform Load(Unrestricted/Restricted) 454kg/300 kg
Gradeability 40 %
Max.Working Slope X-5°/Y-5°
Turret Rotation 360°(Continuous)
Drive Steering Type 4WD×2WS
Battery(Lithium) 48V/460Ah
Charger 48V/80A
Hydraulic Oil Tank 100 L
