FEATURES

Safe And Reliability :Standard dual channel sensor, safe and reliable;Electric emergency power systems provide more security;The protection level of components of the whole machine is above IP65, the protection level is high.

Intelligent And Efficient:Composite action, intelligent and effificient;Electronic differential combined with suspending axle technology for better traffificability;The turntable rotates 360 ° continuously with small tail, which is suitable for narrow space operation;Four wheel strong AC electric drive, climbing capacity up to 45%, strong traffificability;High-power charger, large-capacity power battery, fast charging, ultra-long endurance.

SPECIFICATIONS
Dimensions
Max. Work Height 21.5 m
Max.Platform Height 19.5 m
Max.Operating Range 14 m
Overall Length(Stowed) 10.2 m
Overall Width(Stowed) 2.42 m
Overall Height(Stowed) 2.75 m
Overall Length(Transport) 10.2 m
Overall Width(Transport) 2.29 m
Overall Height(Transport) 2.5 m
Turntable Tailswing(Raised) 1.55 m
Platform Size(L×W×H) 1.83×0.76×1.1 m
Tyres 33×12-20(Solid off-road tyre)
Platform Load(Unrestricted/Restricted) 320 kg
Gradeability 45 %
Max.Working Slope X-5°/Y-5°
Turret Rotation 360°(Continuous)
Drive Steering Type 4WD×2WS
Battery(Lithium) 48V/460Ah
Charger 48V/60A
Hydraulic Oil Tank 100 L
