FEATURES

Security And Intelligence:Intelligent control system, real-time monitoring of equipment status;Multiple security protection to ensure personnel safety;Intelligent charging system to extend battery life.

Easy To Control:Drivable at full height to improve working effificiency;The proportion drops and the descent moves smoothly;Forklift pocket, easy to load, unload and transport.

Maintenance Friendly:Self-lubricating sleeve;Swing-our tray on both sides,easy maintenance;Fault code indication to facilicate troubleshooting.

SPECIFICATIONS
Dimensions
Max.Work Height 16/8 m
Max.Platform Height 14/6 m
Min.Platform Height 1.66 m
Platform Size(L×W) 2.28*1.35 m
Overall Length 3.1 m
Overall Width 1.38 m
Overall Height (Rails Down) 1.97 m
Max.Gradeability 25 %
Rated Load on Working Platform 350 kg
Battery 24V / 270Ah
Charger 24V / 30A
Total Weight 3720 kg → 3700 kg
