FEATURES

Security And Intelligence:Intelligent control system, real-time monitoring of equipment status;Multiple security protection to ensure personnel safety;Intelligent charging system to extend battery life.

Easy To Control:Drivable at full height to improve working effificiency;The proportion drops and the descent moves smoothly;Forklift pocket, easy to load, unload and transport.

Maintenance Friendly:Self-lubricating sleeve;Swing-our tray on both sides,easy maintenance;Fault code indication to facilicate troubleshooting.

SPECIFICATIONS
Dimensions
Max.Work Height 15.7 m
Max.Platform Height 13.7 m
Min.Platform Height 1.48 m
Platform Size(L×W) 2.64 x 1.15m
Overall Length 2.84 m
Overall Width 1.25 m
Overall Height (Rails Down) 2.06 m
Max.Gradeability 25%
Lift Motor 24VAC/3.3kW
Rated Load on Working Platform 250 kg
Battery 24V/270Ah
Charger 24V/30A
Total Weight 3300 kg
