FEATURES

Security And Intelligence:Intelligent control system, real-time monitoring of equipment status;Multiple security protection to ensure personnel safety;Intelligent charging system to extend battery life.

Easy To Control:Drivable at full height to improve working effificiency;The proportion drops and the descent moves smoothly;Forklift pocket, easy to load, unload and transport.

Maintenance Friendly:Self-lubricating sleeve;Swing-our tray on both sides,easy maintenance;Fault code indication to facilicate troubleshooting.

SPECIFICATIONS
Dimensions
Max. Work Height 10 m
Max.Platform Height 8 m
Min.Platform Height 1.22 m
Platform Size(L×W) 2.28×1.15 m
Overall Length 2.49 m
Overall Width 1.19 m →0.844m
Overall Height (Rails Down) 1.8 m
Max.Gradeability 25 %
Lift Motor 24 V / 3.3 kW
Rated Load on Working Platform 450 kg → 230kg
Battery 24 V / 200 Ah
Charger 24 V / 30 A
Total Weight 2520 kg→2180 kg
