FEATURES
PERFORMANCE CHARACTERISTICS
  • Engine and gear box design give you more time to work, making maintenance faster and simpler.
  • Reasonable matching of vibration mass and vibration parameters, high construction efficiency and reasonable vibration intensity can protect the surrounding buildings.
  • Spacious cab with AC, outstanding visibility and three-stage suspension  system provide operator higher productivity.
SPECIFICATIONS
Base
Operating Mass 6,000 kg
Front Drum Static Linear Load 180 N/cm
Engine
Model 4B5-50M22
Emission Regulation China II
Rated Power 36.8 kW@ 2,400 rpm
Compaction
Vibration Frequency 45 Hz
Nominal Amplitude 0.7 mm
Centrifugal Force 94 kN
Drum Diameter 1,060 mm
Drum Width 1,450 mm
Drive
1st Maximum Speed,fwd 2 km/h
2nd Maximum Speed,fwd 7 km/h
Min. Outside Turning Radius 5,470 mm
Min. Ground Clearance 310 mm
Theoretical Gradeability 30%
Dimensions
Overall Length 4,380 mm
Overall Width 1,580 mm
Overall Height 2,500 mm
